Manufacturer Part Number: | LMZ12008TZE/NOPB |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | DC DC Converters |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IC BUCK SYNC 20V 8A TO-PMOD-11 |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LMZ12008TZE/NOPB Datasheet |
Internal Part Number | 898-LMZ12008TZE/NOPB | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | SIMPLE SWITCHER Power Modules Powering FPGAs with SIMPLE SWITCHER® LMZ3 Power Modules SIMPLE SWITCHER® DC-DC Regulator and Module Portfolio Overview | |
Video File | Power Design Invitational - Another Geek Moment Wide VIN Power Design with LMZ3 SIMPLE SWITCHER Power Module SIMPLE SWITCHER® Power Modules with High Power Density SIMPLE SWITCHER Synchronous Regulator Family Overview The Most Interesting Engineer in the World Layout Tips for Radiated EMI Reduction in Your Designs Thermal Design Made Simple Loop Compensation Made SIMPLE WEBENCH PCB Export for Synchronous SIMPLE SWITCHER Devices | |
Design Resources | LMZ12008 Design with WEBENCH® Power Designer | |
Featured Product | Create your power design now with TI’s WEBENCH® Designer Analog Solutions for Xilinx FPGAs and CPLDs – Texas Instruments | DigiKey | |
Reference Design Library | LMZ12008EVAL: 5V@8A, 6~20V in, Inductor On-Chip | |
PCN Design/Specification | Die Coating Material Update 14/Sep/2015 LMZ1X/LMZ2X/WPMDH1X 22/Jul/2016 | |
Manufacturer Product Page | LMZ12008TZE/NOPB Specifications | |
Category | Power Supplies - Board Mount | |
Family | DC DC Converters | |
Manufacturer | Texas Instruments | |
Series | SIMPLE SWITCHER® | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Non-Isolated PoL Module | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 6V | |
Voltage - Input (Max) | 20V | |
Voltage - Output 1 | 0.8 ~ 6 V | |
Voltage - Output 2 | - | |
Voltage - Output 3 | - | |
Current - Output (Max) | 8A | |
Power (Watts) - Manufacture Series | - | |
Voltage - Isolation | - | |
Applications | ITE (Commercial) | |
Features | UVLO | |
Mounting Type | Surface Mount | |
Package / Case | TO-PMOD-11, Power Module | |
Size / Dimension | 0.59" L x 0.59" W x 0.23" H (15.0mm x 15.0mm x 5.9mm) | |
Operating Temperature | -40°C ~ 125°C | |
Efficiency | 92% | |
Power (Watts) - Max | 48W | |
Standard Package | 250 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LMZ12008TZE/NOPB | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
LMZ12008TZE/NOPB is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of LMZ12008TZE/NOPB is new and unused, you can buy LMZ12008TZE/NOPB Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LMZ12008TZE/NOPB.
