Manufacturer Part Number: | LM5113TMX/NOPB |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | PMIC - Gate Drivers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IC GATE DRVR HALF BRDG 5A 12SMD |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LM5113TMX/NOPB Datasheet |
Internal Part Number | 898-LM5113TMX/NOPB | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Driving eGaN FETs with the LM5113 | |
Reference Design Library | EPC9101: eGAN Buck, 1.2V @ 18A, 9 ~ 18V in EPC9102: 12V @ 8 ~ 17A, 48V in EPC9107: 3.3V @ 15A, 9 ~ 28V in LM5113LLPEVB: 10V @ 10A, 15 ~ 60V in | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Gate Drivers | |
Manufacturer | Texas Instruments | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Driven Configuration | Half-Bridge | |
Channel Type | Independent | |
Number of Drivers | 2 | |
Gate Type | N-Channel MOSFET | |
Voltage - Supply | 4.5 V ~ 5.5 V | |
Logic Voltage - VIL, VIH | 1.76V, 1.89V | |
Current - Peak Output (Source, Sink) | 1.2A, 5A | |
Input Type | Non-Inverting | |
High Side Voltage - Max (Bootstrap) | 107V | |
Rise / Fall Time (Typ) | 7ns, 1.5ns | |
Operating Temperature | -40°C ~ 125°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | 12-WFBGA, DSBGA | |
Supplier Device Package | 12-DSBGA | |
Standard Package | 3,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LM5113TMX/NOPB | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
LM5113TMX/NOPB is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of LM5113TMX/NOPB is new and unused, you can buy LM5113TMX/NOPB Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LM5113TMX/NOPB.
