| Manufacturer Part Number: | LM3S1651-IBZ80-C3 |
|---|---|
| Manufacturer: | Texas Instruments |
| Product Category: | Embedded - Microcontrollers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | ARM® Cortex®-M3 Stellaris® ARM® Cortex®-M3S 1000 Microcontroller IC 32-Bit 80MHz 128KB (128K x 8) FLASH 108-BGA (10x10) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | LM3S1651-IBZ80-C3 Datasheet |
| Internal Part Number | 898-LM3S1651-IBZ80-C3 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Intro to Timers and Clocks Microcontrollers: SYS/BIOS: Introduction to Real-Time Operating Systems and SYS/BIOS | |
| Design Resources | Development Tool Selector | |
| PCN Obsolescence/ EOL | TEMPEST/INFERNO LM3S Devices 01/Jul/2014 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Manufacturer | Texas Instruments | |
| Series | Stellaris® ARM® Cortex®-M3S 1000 | |
| Packaging | Tray | |
| Part Status | Obsolete | |
| Core Processor | ARM® Cortex®-M3 | |
| Core Size | 32-Bit | |
| Speed | 80MHz | |
| Connectivity | I²C, IrDA, LIN, Microwire, QEI, SPI, SSI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | |
| Number of I/O | 67 | |
| Program Memory Size | 128KB (128K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 32K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.08 V ~ 3.6 V | |
| Data Converters | A/D 16x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 108-LFBGA | |
| Supplier Device Package | 108-BGA (10x10) | |
| Standard Package | 184 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | LM3S1651-IBZ80-C3 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
LM3S1651-IBZ80-C3 is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of LM3S1651-IBZ80-C3 is new and unused, you can buy LM3S1651-IBZ80-C3 Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LM3S1651-IBZ80-C3.
