Manufacturer Part Number: | LM3686TLE-AAEF/NOPB |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | PMIC - Voltage Regulators - Linear + Switching |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Linear And Switching Voltage Regulator IC 3 Output Step-Down (Buck) Synchronous (1), Linear (LDO) (2) 3MHz 12-WFBGA, DSBGA |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LM3686TLE-AAEF/NOPB Datasheet |
Internal Part Number | 898-LM3686TLE-AAEF/NOPB | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Assembly/Origin | Wafer Process BCB Elimnation 12/Feb/2014 Wafer Process Revision A 14/Jul/2014 | |
EDA / CAD Models | Download from Accelerated Designs | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Voltage Regulators - Linear + Switching | |
Manufacturer | Texas Instruments | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
Topology | Step-Down (Buck) Synchronous (1), Linear (LDO) (2) | |
Function | Any Function | |
Number of Outputs | 3 | |
Frequency - Switching | 3MHz | |
Voltage/Current - Output 1 | 1.8V, 600mA | |
Voltage/Current - Output 2 | 1.2V, 350mA | |
Voltage/Current - Output 3 | 3V, 300mA | |
w/LED Driver | No | |
w/Supervisor | No | |
w/Sequencer | No | |
Voltage - Supply | 2.7 V ~ 5.5 V | |
Operating Temperature | -40°C ~ 85°C | |
Mounting Type | Surface Mount | |
Package / Case | 12-WFBGA, DSBGA | |
Supplier Device Package | 12-DSBGA | |
Standard Package | 250 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LM3686TLE-AAEF/NOPB | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
LM3686TLE-AAEF/NOPB is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of LM3686TLE-AAEF/NOPB is new and unused, you can buy LM3686TLE-AAEF/NOPB Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LM3686TLE-AAEF/NOPB.
