Manufacturer Part Number: | LM22676TJ-ADJ/NOPB |
---|---|
Manufacturer: | Texas Instruments |
Product Category: | PMIC - Voltage Regulators - DC DC Switching Regulators |
Available Quantity: | 11010 Pieces |
Unit Price: | Quote by Email |
Description: | Buck Switching Regulator IC Positive Adjustable 1.285V 1 Output 3A TO-263-7 Thin |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | LM22676TJ-ADJ/NOPB Datasheet |
Internal Part Number | 898-LM22676TJ-ADJ/NOPB | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | SIMPLE SWITCHER® Regulators LM315x & LM2267x SIMPLE SWITCHER® and WEBENCH Powering FPGAs with SIMPLE SWITCHER® LMZ3 Power Modules | |
Video File | Wide VIN Power Design with LMZ3 SIMPLE SWITCHER Power Module SIMPLE SWITCHER® Power Modules with High Power Density SIMPLE SWITCHER Synchronous Regulator Family Overview The Most Interesting Engineer in the World Layout Tips for Radiated EMI Reduction in Your Designs Thermal Design Made Simple Loop Compensation Made SIMPLE WEBENCH PCB Export for Synchronous SIMPLE SWITCHER Devices | |
Design Resources | LM22676 Design with WEBENCH® Power Designer | |
Featured Product | Create your power design now with TI’s WEBENCH® Designer Analog Solutions for Xilinx FPGAs and CPLDs – Texas Instruments | DigiKey | |
PCN Assembly/Origin | Wafer Fab Qualification 07/Oct/2014 | |
Manufacturer Product Page | LM22676TJ-ADJ/NOPB Specifications | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | Buck (Step-Down) IC | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
Manufacturer | Texas Instruments | |
Series | SIMPLE SWITCHER® | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Function | Step-Down | |
Output Configuration | Positive | |
Topology | Buck | |
Output Type | Adjustable | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 4.5V | |
Voltage - Input (Max) | 42V | |
Voltage - Output (Min/Fixed) | 1.285V | |
Voltage - Output (Max) | 37V | |
Current - Output | 3A | |
Frequency - Switching | 500kHz | |
Synchronous Rectifier | No | |
Operating Temperature | -40°C ~ 125°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | TO-263-7 Thin | |
Supplier Device Package | TO-263-7 Thin | |
Standard Package | 1,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | LM22676TJ-ADJ/NOPB | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
LM22676TJ-ADJ/NOPB is in stock for immediate shipping now. We are the distributor of Texas Instruments all series components. The condition of LM22676TJ-ADJ/NOPB is new and unused, you can buy LM22676TJ-ADJ/NOPB Texas Instruments with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LM22676TJ-ADJ/NOPB.
