LDA200STR

LDA200STR
Manufacturer Part Number:LDA200STR
Manufacturer:
Product Category:Optoisolators - Transistor, Photovoltaic Output
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:Optoisolator Transistor Output 3750Vrms 2 Channel 8-SMD
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: LDA200STR Datasheet
LDA200STR´s Parameters
Internal Part Number898-LDA200STR
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
CategoryIsolators
FamilyOptoisolators - Transistor, Photovoltaic Output
ManufacturerIXYS Integrated Circuits Division
Series-
PackagingTape & Reel (TR)
Part StatusActive
Number of Channels2
Voltage - Isolation3750Vrms
Current Transfer Ratio (Min)33% @ 1mA
Current Transfer Ratio (Max)1000% @ 1mA
Turn On / Turn Off Time (Typ)7µs, 20µs
Rise / Fall Time (Typ)-
Input TypeAC, DC
Output TypeTransistor
Voltage - Output (Max)30V
Current - Output / Channel-
Voltage - Forward (Vf) (Typ)1.2V
Current - DC Forward (If) (Max)1mA
Vce Saturation (Max)500mV
Operating Temperature-40°C ~ 85°C
Mounting TypeSurface Mount
Package / Case8-SMD, Gull Wing
Supplier Device Package8-SMD
Standard Package 1,000
Weight0.001 KG
ApplicationEmail for details
Replacement PartLDA200STR
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

LDA200STR is in stock for immediate shipping now. We are the distributor of IXYS Integrated Circuits Division all series components. The condition of LDA200STR is new and unused, you can buy LDA200STR IXYS Integrated Circuits Division with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for LDA200STR.
