| Manufacturer Part Number: | LCM-S12232GSF |
|---|---|
| Manufacturer: | Lumex Opto/Components Inc. |
| Product Category: | Display Modules - LCD, OLED, Graphic |
| Available Quantity: | 9076 Pieces |
| Unit Price: | Quote by Email |
| Description: | Graphic LCD Display Module Transflective Gray STN - Super-Twisted Nematic Parallel, 8-Bit 122 x 32 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | LCM-S12232GSF Datasheet |
| Internal Part Number | 898-LCM-S12232GSF | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | LEDs LCD Technology Benefits of Custom LED and LCD Technology Bi-Stable LCD Technology | |
| RoHS Information | RoHS Cert of Compliance | |
| Online Catalog | InfoVue™ TFT LCD Modules | |
| Category | Optoelectronics | |
| Family | Display Modules - LCD, OLED, Graphic | |
| Manufacturer | Lumex Opto/Components Inc. | |
| Series | - | |
| Part Status | Active | |
| Display Type | STN - Super-Twisted Nematic | |
| Display Mode | Transflective | |
| Touchscreen | - | |
| Diagonal Screen Size | - | |
| Viewing Area | 60.50mm W x 18.50mm H | |
| Backlight | LED - Yellow/Green | |
| Dot Pixels | 122 x 32 | |
| Interface | Parallel, 8-Bit | |
| Graphics Color | Gray | |
| Background Color | Green | |
| Dot Size | 0.40mm W x 0.45mm H | |
| Dot Pitch | 0.44mm W x 0.49mm H | |
| Standard Package | 45 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | LCM-S12232GSF | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
LCM-S12232GSF is in stock for immediate shipping now. We are the distributor of Lumex Opto/Components Inc. all series components. The condition of LCM-S12232GSF is new and unused, you can buy LCM-S12232GSF Lumex Opto/Components Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LCM-S12232GSF.
