| Manufacturer Part Number: | KT2520Y40000ECV28TBA |
|---|---|
| Manufacturer: | AVX Corp/Kyocera Corp |
| Product Category: | Oscillators |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 40MHz Clipped Sine Wave TCXO Oscillator Surface Mount 2.8V 2mA |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | KT2520Y40000ECV28TBA Datasheet |
| Internal Part Number | 898-KT2520Y40000ECV28TBA | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | TCXOs for GPS and Cell Phone Applications | |
| Category | Crystals and Oscillators | |
| Family | Oscillators | |
| Manufacturer | AVX Corp/Kyocera Corp | |
| Series | KT2520Y, Kyocera | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Type | TCXO | |
| Frequency | 40MHz | |
| Function | - | |
| Output | Clipped Sine Wave | |
| Voltage - Supply | 2.8V | |
| Frequency Stability | ±2.5ppm | |
| Operating Temperature | -30°C ~ 80°C | |
| Current - Supply (Max) | 2mA | |
| Ratings | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) | |
| Height | 0.035" (0.90mm) | |
| Package / Case | 6-SMD, No Lead (DFN, LCC) | |
| Current - Supply (Disable) (Max) | - | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | KT2520Y40000ECV28TBA | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
KT2520Y40000ECV28TBA is in stock for immediate shipping now. We are the distributor of AVX Corp/Kyocera Corp all series components. The condition of KT2520Y40000ECV28TBA is new and unused, you can buy KT2520Y40000ECV28TBA AVX Corp/Kyocera Corp with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for KT2520Y40000ECV28TBA.
