| Manufacturer Part Number: | KSZ8462HLI-EVAL |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | KSZ8462HLI EtherSynch™ Series Interface, Ethernet Controller (PHY and MAC) Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | KSZ8462HLI-EVAL Datasheet |
| Internal Part Number | 898-KSZ8462HLI-EVAL | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Management Interfaces for Micrel Switches KSZ84xx GPIO Pin Output Functionality Updating PTP Software on the KSZ9692 SoC 2-MII Board and the SoC Test Board Power and Reset Requirements for the KSZ84xx EtherSynch® Family | |
| Design Resources | KSZ8462-8441 Eval Board Schematic Development Tool Selector | |
| Featured Product | IEEE1588v2 Ethernet | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | EtherSynch™ | |
| Part Status | Discontinued | |
| Main Purpose | Interface, Ethernet Controller (PHY and MAC) | |
| Embedded | - | |
| Utilized IC / Part | KSZ8462HLI | |
| Primary Attributes | - | |
| Secondary Attributes | - | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | KSZ8462HLI-EVAL | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
KSZ8462HLI-EVAL is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of KSZ8462HLI-EVAL is new and unused, you can buy KSZ8462HLI-EVAL Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for KSZ8462HLI-EVAL.
