KC15A9.501NPF

KC15A9.501NPF
Manufacturer Part Number:KC15A9.501NPF
Manufacturer:
Product Category:Rotary Switches
Available Quantity:9762 Pieces
Unit Price:Quote by Email
Description:Rotary Switch 5 Position SP5T 350mA (AC) 125VAC Panel Mount, Through Hole
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: KC15A9.501NPF Datasheet
KC15A9.501NPF´s Parameters
Internal Part Number898-KC15A9.501NPF
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
RoHS InformationKC Series RoHS Cert of Compliance
3D ModelKC15A9.501xPx.stp
Online Catalog KC Series
CategorySwitches
FamilyRotary Switches
ManufacturerE-Switch
SeriesKC
Part StatusActive
Number of Positions5
Index StopsFixed
Number of Decks1
Number of Poles per Deck1
Circuit per DeckSP5T
Contact TimingNon-Shorting (BBM)
Current Rating350mA (AC)
Voltage Rating - AC125V
Voltage Rating - DC-
Actuator TypeFlatted (6.35mm Dia)
Actuator Length9.50mm
Angle of Throw30°
Contact MaterialCopper Alloy
Contact FinishGold
Mounting TypePanel Mount, Through Hole
Termination StylePC Pin
Features-
Depth Behind Panel14.20mm
Panel Cutout DimensionsCircular - 9.80mm Dia
Operating Force, Torque800 g-cm
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement PartKC15A9.501NPF
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

KC15A9.501NPF is in stock for immediate shipping now. We are the distributor of E-Switch all series components. The condition of KC15A9.501NPF is new and unused, you can buy KC15A9.501NPF E-Switch with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for KC15A9.501NPF.
