Manufacturer Part Number: | JN5121-000-M00T |
---|---|
Manufacturer: | NXP Semiconductors |
Product Category: | RF Transceiver Modules |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | RF TXRX MOD 802.15.4 TRACE ANT |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | JN5121-000-M00T Datasheet |
Internal Part Number | 898-JN5121-000-M00T | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector IoT Product Selector | |
Category | RF/IF and RFID | |
Family | RF Transceiver Modules | |
Manufacturer | NXP Semiconductors | |
Series | JN5121-000-M0xx | |
Packaging | Tape & Reel (TR) | |
Part Status | Obsolete | |
RF Family/Standard | 802.15.4 | |
Protocol | Zigbee® | |
Modulation | - | |
Frequency | 2.4GHz | |
Data Rate | - | |
Power - Output | 0dBm | |
Sensitivity | -90dBm | |
Serial Interfaces | I²C, SPI, UART | |
Antenna Type | Integrated, Trace | |
Memory Size | 64kB ROM, 96kB RAM | |
Voltage - Supply | 2.2 V ~ 3.6 V | |
Current - Receiving | 50mA | |
Current - Transmitting | 45mA | |
Mounting Type | Surface Mount | |
Operating Temperature | -40°C ~ 85°C | |
Package / Case | - | |
Standard Package | 500 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | JN5121-000-M00T | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
JN5121-000-M00T is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of JN5121-000-M00T is new and unused, you can buy JN5121-000-M00T NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for JN5121-000-M00T.
