| Manufacturer Part Number: | JAN1N3338B |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | Diodes - Zener - Single |
| Available Quantity: | 9012 Pieces |
| Unit Price: | Quote by Email |
| Description: | Zener Diode 82V 50W ±5% Stud Mount DO-203AB |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | JAN1N3338B Datasheet |
| Internal Part Number | 898-JAN1N3338B | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | High-Reliability Semiconductors | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Manufacturer | Microsemi IRE Division | |
| Series | - | |
| Packaging | Bulk | |
| Part Status | Quote Required | |
| Voltage - Zener (Nom) (Vz) | 82V | |
| Tolerance | ±5% | |
| Power - Max | 50W | |
| Impedance (Max) (Zzt) | 11 Ohm | |
| Current - Reverse Leakage @ Vr | 10µA @ 62.2V | |
| Voltage - Forward (Vf) (Max) @ If | 1.5V @ 10A | |
| Operating Temperature | -65°C ~ 175°C | |
| Mounting Type | Stud Mount | |
| Package / Case | DO-203AB, DO-5, Stud | |
| Supplier Device Package | DO-203AB | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | JAN1N3338B | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
JAN1N3338B is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of JAN1N3338B is new and unused, you can buy JAN1N3338B Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for JAN1N3338B.
