| Manufacturer Part Number: | IXTA96P085TTRL |
|---|---|
| Manufacturer: | IXYS |
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Available Quantity: | 11410 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET P-CH 85V 96A TO-263 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | IXTA96P085TTRL Datasheet |
| Internal Part Number | 898-IXTA96P085TTRL | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Online Catalog | P-Channel Standard FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Single | |
| Manufacturer | IXYS | |
| Series | TrenchP™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| FET Type | MOSFET P-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 85V | |
| Current - Continuous Drain (Id) @ 25°C | 96A (Tc) | |
| Rds On (Max) @ Id, Vgs | 13 mOhm @ 48A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 180nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 13100pF @ 25V | |
| Power - Max | 298W | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | TO-263 (IXTA) | |
| Standard Package | 800 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | IXTA96P085TTRL | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
IXTA96P085TTRL is in stock for immediate shipping now. We are the distributor of IXYS all series components. The condition of IXTA96P085TTRL is new and unused, you can buy IXTA96P085TTRL IXYS with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IXTA96P085TTRL.
