Manufacturer Part Number: | IXST40N60B2D1 |
---|---|
Manufacturer: | IXYS |
Product Category: | Transistors - IGBTs - Single |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IGBT PT 600V 48A Surface Mount TO-268 |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | IXST40N60B2D1 Datasheet |
Internal Part Number | 898-IXST40N60B2D1 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Obsolescence/ EOL | IGBT's S Class Type 23/Apr/2013 | |
Category | Discrete Semiconductor Products | |
Family | Transistors - IGBTs - Single | |
Manufacturer | IXYS | |
Series | - | |
Packaging | Bulk | |
Part Status | Obsolete | |
IGBT Type | PT | |
Voltage - Collector Emitter Breakdown (Max) | 600V | |
Current - Collector (Ic) (Max) | 48A | |
Current - Collector Pulsed (Icm) | - | |
Vce(on) (Max) @ Vge, Ic | - | |
Power - Max | - | |
Switching Energy | - | |
Input Type | Standard | |
Gate Charge | - | |
Td (on/off) @ 25°C | - | |
Test Condition | - | |
Reverse Recovery Time (trr) | - | |
Package / Case | TO-268-3, D³Pak (2 Leads + Tab), TO-268AA | |
Mounting Type | Surface Mount | |
Supplier Device Package | TO-268 | |
Standard Package | 30 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | IXST40N60B2D1 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
IXST40N60B2D1 is in stock for immediate shipping now. We are the distributor of IXYS all series components. The condition of IXST40N60B2D1 is new and unused, you can buy IXST40N60B2D1 IXYS with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IXST40N60B2D1.
