| Manufacturer Part Number: | IXDD409YI |
|---|---|
| Manufacturer: | IXYS |
| Product Category: | PMIC - Gate Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC HIGH CURR GATE DRVR 9A TO-263 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | IXDD409YI Datasheet |
| Internal Part Number | 898-IXDD409YI | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 15/Jun/2010 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Manufacturer | IXYS | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Obsolete | |
| Driven Configuration | Low-Side | |
| Channel Type | Single | |
| Number of Drivers | 1 | |
| Gate Type | IGBT, N-Channel, P-Channel MOSFET | |
| Voltage - Supply | 4.5 V ~ 35 V | |
| Logic Voltage - VIL, VIH | 0.8V, 3.5V | |
| Current - Peak Output (Source, Sink) | 9A, 9A | |
| Input Type | Non-Inverting | |
| High Side Voltage - Max (Bootstrap) | - | |
| Rise / Fall Time (Typ) | 10ns, 10ns | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-6, D²Pak (5 Leads + Tab), TO-263BA | |
| Supplier Device Package | TO-263 (D²Pak) | |
| Standard Package | 50 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | IXDD409YI | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
IXDD409YI is in stock for immediate shipping now. We are the distributor of IXYS all series components. The condition of IXDD409YI is new and unused, you can buy IXDD409YI IXYS with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IXDD409YI.
