.jpg)
| Manufacturer Part Number: | ISLA224P20IRZ |
|---|---|
| Manufacturer: | Intersil |
| Product Category: | Data Acquisition - Analog to Digital Converters (ADC) |
| Available Quantity: | 9018 Pieces |
| Unit Price: | Quote by Email |
| Description: | 14 Bit Analog to Digital Converter 2 Input 1 SAR 72-QFN (10x10) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ISLA224P20IRZ Datasheet |
| Internal Part Number | 898-ISLA224P20IRZ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | 14 Bit | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Manufacturer | Intersil | |
| Series | - | |
| Packaging | Tray | |
| Part Status | Active | |
| Number of Bits | 14 | |
| Sampling Rate (Per Second) | 125M | |
| Number of Inputs | 2 | |
| Input Type | Differential | |
| Data Interface | LVDS - Parallel, Parallel | |
| Configuration | S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | SAR | |
| Reference Type | Internal | |
| Voltage - Supply, Analog | 1.7 V ~ 1.9 V | |
| Voltage - Supply, Digital | 1.7 V ~ 1.9 V | |
| Features | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 72-VFQFN Exposed Pad | |
| Supplier Device Package | 72-QFN (10x10) | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ISLA224P20IRZ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ISLA224P20IRZ is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ISLA224P20IRZ is new and unused, you can buy ISLA224P20IRZ Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ISLA224P20IRZ.
