Manufacturer Part Number: | ISL6558IRZR5240 |
---|---|
Manufacturer: | Intersil |
Product Category: | PMIC - Voltage Regulators - DC DC Switching Controllers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Buck Regulator Positive Output Step-Down DC-DC Controller IC 20-QFN-EP (5x5) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 2 (1 Year) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ISL6558IRZR5240 Datasheet |
Internal Part Number | 898-ISL6558IRZR5240 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Obsolescence/ EOL | Multiple Devices 10/Jun/2015 | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
Manufacturer | Intersil | |
Series | - | |
Packaging | Tube | |
Part Status | Discontinued | |
Output Type | PWM Signal | |
Function | Step-Down | |
Output Configuration | Positive | |
Topology | Buck | |
Number of Outputs | 4 | |
Output Phases | 4 | |
Voltage - Supply (Vcc/Vdd) | 4.75 V ~ 5.25 V | |
Frequency - Switching | 80kHz ~ 1.5MHz | |
Duty Cycle (Max) | 75% | |
Synchronous Rectifier | - | |
Clock Sync | No | |
Serial Interfaces | - | |
Control Features | Enable, Frequency Control, Power Good | |
Operating Temperature | -40°C ~ 85°C (TA) | |
Package / Case | 20-VQFN Exposed Pad | |
Supplier Device Package | 20-QFN-EP (5x5) | |
Standard Package | 60 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ISL6558IRZR5240 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ISL6558IRZR5240 is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ISL6558IRZR5240 is new and unused, you can buy ISL6558IRZR5240 Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ISL6558IRZR5240.
