| Manufacturer Part Number: | ISL6540AIRZA |
|---|---|
| Manufacturer: | Intersil |
| Product Category: | PMIC - Voltage Regulators - DC DC Switching Controllers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Buck Regulator Positive Output Step-Down DC-DC Controller IC 28-QFN (5x5) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ISL6540AIRZA Datasheet |
| Internal Part Number | 898-ISL6540AIRZA | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Application: Industrial Controls | |
| PCN Assembly/Origin | DFN/QFN Alternate Manufacturing Site 25/Oct/2013 Wafer Fab Site Transfer 09/Jul/2014 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Manufacturer | Intersil | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Active | |
| Output Type | Transistor Driver | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Number of Outputs | 1 | |
| Output Phases | 1 | |
| Voltage - Supply (Vcc/Vdd) | 2.97 V ~ 22 V | |
| Frequency - Switching | 250kHz ~ 2MHz | |
| Duty Cycle (Max) | 100% | |
| Synchronous Rectifier | Yes | |
| Clock Sync | No | |
| Serial Interfaces | - | |
| Control Features | Current Limit, Enable, Frequency Control, Power Good, Soft Start | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 28-VFQFN Exposed Pad | |
| Supplier Device Package | 28-QFN (5x5) | |
| Standard Package | 60 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ISL6540AIRZA | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ISL6540AIRZA is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of ISL6540AIRZA is new and unused, you can buy ISL6540AIRZA Intersil with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ISL6540AIRZA.
