Manufacturer Part Number: | IRSM515-055DA |
---|---|
Manufacturer: | Infineon Technologies |
Product Category: | PMIC - Full, Half-Bridge Drivers |
Available Quantity: | 9100 Pieces |
Unit Price: | Quote by Email |
Description: | IC MOTOR DRIVER 500V 23DIP |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | IRSM515-055DA Datasheet |
Internal Part Number | 898-IRSM515-055DA | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Assembly/Origin | Warehouse Transfer 29/Jul/2015 | |
Online Catalog | Full, Half-Bridge Drivers | |
Category | Integrated Circuits (ICs) | |
Family | PMIC - Full, Half-Bridge Drivers | |
Manufacturer | Infineon Technologies | |
Series | µIPM™-DIP | |
Packaging | Tube | |
Part Status | Active | |
Output Configuration | Half Bridge (3) | |
Applications | AC Motors | |
Interface | Logic | |
Load Type | Inductive | |
Technology | UMOS | |
Rds On (Typ) | 1.3 Ohm | |
Current - Output / Channel | 2.4A | |
Current - Peak Output | 15A | |
Voltage - Supply | 13.5 V ~ 16.5 V | |
Voltage - Load | 400V (Max) | |
Operating Temperature | -40°C ~ 150°C (TJ) | |
Features | Bootstrap Circuit | |
Fault Protection | UVLO | |
Mounting Type | Through Hole | |
Package / Case | 23-DIP Module | |
Supplier Device Package | 23-DIP | |
Standard Package | 15 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | IRSM515-055DA | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
IRSM515-055DA is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of IRSM515-055DA is new and unused, you can buy IRSM515-055DA Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IRSM515-055DA.
