Manufacturer Part Number: | IRPLDIM3 |
---|---|
Manufacturer: | Infineon Technologies |
Product Category: | Evaluation and Demonstration Boards and Kits |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | IRS2158D - Lighting, Ballast Control Evaluation Board |
Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | IRPLDIM3 Datasheet |
Internal Part Number | 898-IRPLDIM3 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) | |
Design Resources | Development Tool Selector | |
Category | Programmers, Development Systems | |
Family | Evaluation and Demonstration Boards and Kits | |
Manufacturer | Infineon Technologies | |
Series | - | |
Part Status | Not For New Designs | |
Main Purpose | Lighting, Ballast Control | |
Embedded | No | |
Utilized IC / Part | IRS2158D | |
Primary Attributes | 28W TL5, Dimmable, PFC, Open Lamp and End of Life and Brown-out Protection | |
Secondary Attributes | Preheating Ignition | |
Supplied Contents | Board | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | IRPLDIM3 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
IRPLDIM3 is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of IRPLDIM3 is new and unused, you can buy IRPLDIM3 Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IRPLDIM3.
