Manufacturer Part Number: | IRFU3709ZPBF |
---|---|
Manufacturer: | Infineon Technologies |
Product Category: | Transistors - FETs, MOSFETs - Single |
Available Quantity: | 9840 Pieces |
Unit Price: | Quote by Email |
Description: | MOSFET N-CH 30V 86A I-PAK |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | IRFU3709ZPBF Datasheet |
Internal Part Number | 898-IRFU3709ZPBF | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | High Voltage Integrated Circuits (HVIC Gate Drivers) Discrete Power MOSFETs 40V and Below | |
Design Resources | IRFR3709Z Saber Model IRFR3709Z Spice Model | |
PCN Obsolescence/ EOL | Mult Device EOL 11/May/2016 Mult Dev EOL 15/May/2016 | |
PCN Design/Specification | Leadframe Update 02/Jun/2015 Leadframe Retraction 03/Jun/2015 | |
PCN Assembly/Origin | Backend Wafer Transfer 23/Oct/2013 Assembly Site Addition 30/Jun/2014 | |
PCN Packaging | Package Drawing Update 19/Aug/2015 | |
Online Catalog | N-Channel Standard FETs | |
Category | Discrete Semiconductor Products | |
Family | Transistors - FETs, MOSFETs - Single | |
Manufacturer | Infineon Technologies | |
Series | HEXFET® | |
Packaging | Tube | |
Part Status | Last Time Buy | |
FET Type | MOSFET N-Channel, Metal Oxide | |
FET Feature | Standard | |
Drain to Source Voltage (Vdss) | 30V | |
Current - Continuous Drain (Id) @ 25°C | 86A (Tc) | |
Rds On (Max) @ Id, Vgs | 6.5 mOhm @ 15A, 10V | |
Vgs(th) (Max) @ Id | 2.25V @ 250µA | |
Gate Charge (Qg) @ Vgs | 26nC @ 4.5V | |
Input Capacitance (Ciss) @ Vds | 2330pF @ 15V | |
Power - Max | 79W | |
Operating Temperature | -55°C ~ 175°C (TJ) | |
Mounting Type | Through Hole | |
Package / Case | TO-251-3 Short Leads, IPak, TO-251AA | |
Supplier Device Package | IPAK (TO-251) | |
Standard Package | 75 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | IRFU3709ZPBF | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
IRFU3709ZPBF is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of IRFU3709ZPBF is new and unused, you can buy IRFU3709ZPBF Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IRFU3709ZPBF.
