| Manufacturer Part Number: | IRF3546MTRPBF |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | Transistors - FETs, MOSFETs - Arrays |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | MOSFET 4N-CH 25V 16A/20A 41PQFN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | IRF3546MTRPBF Datasheet |
| Internal Part Number | 898-IRF3546MTRPBF | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Discrete Power MOSFETs 40V and Below | |
| PCN Assembly/Origin | Backend Wafer Transfer 23/Oct/2013 | |
| Online Catalog | N-Channel Logic Level Gate FETs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - FETs, MOSFETs - Arrays | |
| Manufacturer | Infineon Technologies | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| FET Type | 4 N-Channel | |
| FET Feature | Logic Level Gate | |
| Drain to Source Voltage (Vdss) | 25V | |
| Current - Continuous Drain (Id) @ 25°C | 16A (Tc), 20A (Tc) | |
| Rds On (Max) @ Id, Vgs | 3.9 mOhm @ 27A, 10V | |
| Vgs(th) (Max) @ Id | 2.1V @ 35µA | |
| Gate Charge (Qg) @ Vgs | 15nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 1310pF @ 13V | |
| Power - Max | - | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 41-PowerVFQFN | |
| Supplier Device Package | 41-PQFN (6x8) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | IRF3546MTRPBF | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
IRF3546MTRPBF is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of IRF3546MTRPBF is new and unused, you can buy IRF3546MTRPBF Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IRF3546MTRPBF.
