| Manufacturer Part Number: | IL261-1E |
|---|---|
| Manufacturer: | NVE Corp/Sensor Products |
| Product Category: | Digital Isolators |
| Available Quantity: | 9150 Pieces |
| Unit Price: | Quote by Email |
| Description: | General Purpose Digital Isolator 2500Vrms 5 Channel 110Mbps 30kV/µs CMTI 16-SSOP (0.154", 3.90mm Width) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | IL261-1E Datasheet |
| Internal Part Number | 898-IL261-1E | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | IsoLoop® Isolator | |
| Video File | How IsoLoop Isolators Work Isolator Transient Immunity IsoLoop Reliability Isolator High-Voltage Standards Isolator High-Voltage Endurance | |
| Online Catalog | IL260, 261, 262 Series | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Manufacturer | NVE Corp/Isolation Products | |
| Series | IsoLoop® | |
| Packaging | Tube | |
| Part Status | Active | |
| Technology | GMR (Giant Magnetoresistive) | |
| Type | General Purpose | |
| Isolated Power | No | |
| Number of Channels | 5 | |
| Inputs - Side 1/Side 2 | 4/1 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 2500Vrms | |
| Common Mode Transient Immunity (Min) | 30kV/µs | |
| Data Rate | 110Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 15ns, 15ns | |
| Pulse Width Distortion (Max) | 3ns | |
| Rise / Fall Time (Typ) | 1ns, 1ns | |
| Voltage - Supply | 3 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) | |
| Supplier Device Package | 16-QSOP | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | IL261-1E | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
IL261-1E is in stock for immediate shipping now. We are the distributor of NVE Corp/Sensor Products all series components. The condition of IL261-1E is new and unused, you can buy IL261-1E NVE Corp/Sensor Products with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for IL261-1E.
