| Manufacturer Part Number: | ICM0805ER181M |
|---|---|
| Manufacturer: | Vishay BC Components |
| Product Category: | Common Mode Chokes |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 2 Line Common Mode Choke Surface Mount 180 Ohm @ 100MHz 330mA DCR 350 mOhm |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ICM0805ER181M Datasheet |
| Internal Part Number | 898-ICM0805ER181M | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | ICM-0805,ICM-1206 Assembly Site 21/Apr/2016 ICM-0805,1206 Manufacturing 17/Aug/2016 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | ICM-0805 Series | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Manufacturer | Vishay Dale | |
| Series | ICM-0805 | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Filter Type | Signal Line | |
| Number of Lines | 2 | |
| Impedance @ Frequency | 180 Ohm @ 100MHz | |
| Inductance @ Frequency | - | |
| Current Rating (Max) | 330mA | |
| DC Resistance (DCR) (Max) | 350 mOhm | |
| Voltage Rating - DC | 50V | |
| Voltage Rating - AC | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Ratings | - | |
| Approvals | - | |
| Features | - | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 0.079" L x 0.047" W (2.00mm x 1.20mm) | |
| Height (Max) | 0.057" (1.45mm) | |
| Package / Case | Horizontal, 4 PC Pad | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ICM0805ER181M | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ICM0805ER181M is in stock for immediate shipping now. We are the distributor of Vishay BC Components all series components. The condition of ICM0805ER181M is new and unused, you can buy ICM0805ER181M Vishay BC Components with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ICM0805ER181M.
