| Manufacturer Part Number: | ICE2A280Z |
|---|---|
| Manufacturer: | Infineon Technologies |
| Product Category: | PMIC - AC DC Converters, Offline Switchers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Converter Offline Flyback Topology 100kHz PG-DIP-7-1 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | ICE2A280Z Datasheet |
| Internal Part Number | 898-ICE2A280Z | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 05/Dec/2013 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - AC DC Converters, Offline Switchers | |
| Manufacturer | Infineon Technologies | |
| Series | CoolSET®F2 | |
| Packaging | Tube | |
| Part Status | Obsolete | |
| Output Isolation | Isolated | |
| Internal Switch(s) | Yes | |
| Voltage - Breakdown | 800V | |
| Topology | Flyback | |
| Voltage - Start Up | 13.5V | |
| Voltage - Supply (Vcc/Vdd) | 8.5 V ~ 21 V | |
| Duty Cycle | 72% | |
| Frequency - Switching | 100kHz | |
| Power (Watts) | 50W | |
| Fault Protection | Current Limiting, Open Loop, Over Load, Over Temperature, Over Voltage | |
| Control Features | Soft Start | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | 8-DIP (0.300", 7.62mm), 7 Leads | |
| Supplier Device Package | PG-DIP-7-1 | |
| Mounting Type | Through Hole | |
| Standard Package | 2,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | ICE2A280Z | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
ICE2A280Z is in stock for immediate shipping now. We are the distributor of Infineon Technologies all series components. The condition of ICE2A280Z is new and unused, you can buy ICE2A280Z Infineon Technologies with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ICE2A280Z.
