| Manufacturer Part Number: | HV214PJ-G |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Interface - Analog Switches - Special Purpose |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC 8CH ANALOG SWITCH 250V 28PLCC |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | HV214PJ-G Datasheet |
| Internal Part Number | 898-HV214PJ-G | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | HV214 Devices 16/Mar/2015 | |
| PCN Assembly/Origin | Qualification Supertex Devices 22/Jul/2014 Fabrication Site Addition 05/Dec/2014 Qualification Revision 19/Dec/2014 Fab Site Addition 14/Aug/2014 | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Analog Switches - Special Purpose | |
| Manufacturer | Microchip Technology | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Obsolete | |
| Applications | Ultrasound | |
| Multiplexer/Demultiplexer Circuit | 1:1 | |
| Switch Circuit | SPST | |
| Number of Channels | 8 | |
| On-State Resistance (Max) | 55 Ohm | |
| Voltage - Supply, Single (V+) | 40 V ~ 250 V | |
| Voltage - Supply, Dual (V±) | ±40 V ~ 210 V | |
| -3db Bandwidth | 50MHz | |
| Features | - | |
| Operating Temperature | 0°C ~ 70°C (TA) | |
| Package / Case | 28-LCC (J-Lead) | |
| Supplier Device Package | 28-PLCC (11.5x11.5) | |
| Standard Package | 38 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | HV214PJ-G | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
HV214PJ-G is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of HV214PJ-G is new and unused, you can buy HV214PJ-G Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HV214PJ-G.
