Manufacturer Part Number: | HSMN-C190 |
---|---|
Manufacturer: | Broadcom Limited |
Product Category: | LED Indication - Discrete |
Available Quantity: | 25010 Pieces |
Unit Price: | Quote by Email |
Description: | Blue 470nm LED Indication - Discrete 3.3V 0603 (1608 Metric) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 2A (4 Weeks) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HSMN-C190 Datasheet |
Internal Part Number | 898-HSMN-C190 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Design/Specification | New Die Source 30/Sept/2009 | |
PCN Assembly/Origin | Replacement Die Source 18/Feb/2014 | |
Online Catalog | 0603 Blue Rectangle with Flat Top Chip LEDs | |
Category | Optoelectronics | |
Family | LED Indication - Discrete | |
Manufacturer | Broadcom Limited | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Color | Blue | |
Lens Color | White | |
Lens Transparency | Diffused | |
Millicandela Rating | 35mcd | |
Lens Style/Size | Rectangle with Flat Top, 1.00mm x 0.80mm | |
Voltage - Forward (Vf) (Typ) | 3.3V | |
Current - Test | 20mA | |
Viewing Angle | 170° | |
Mounting Type | Surface Mount | |
Wavelength - Dominant | 470nm | |
Wavelength - Peak | 468nm | |
Features | - | |
Package / Case | 0603 (1608 Metric) | |
Supplier Device Package | Chip LED | |
Size / Dimension | 1.60mm L x 0.80mm W | |
Height (Max) | 0.80mm | |
Standard Package | 4,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HSMN-C190 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HSMN-C190 is in stock for immediate shipping now. We are the distributor of Broadcom Limited all series components. The condition of HSMN-C190 is new and unused, you can buy HSMN-C190 Broadcom Limited with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HSMN-C190.
