Manufacturer Part Number: | HRM-503(40) |
---|---|
Manufacturer: | Hirose Electric Co Ltd |
Product Category: | Coaxial Connectors (RF) - Adapters |
Available Quantity: | 9043 Pieces |
Unit Price: | Quote by Email |
Description: | Adapter Coaxial Connector SMA Plug, Male Pin To SMA Jack, Female Socket 50 Ohm |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HRM-503(40) Datasheet |
Internal Part Number | 898-HRM-503(40) | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | Coaxial, RF Adapters | |
Category | Connectors, Interconnects | |
Family | Coaxial Connectors (RF) - Adapters | |
Manufacturer | Hirose Electric Co Ltd | |
Series | HRM | |
Packaging | Bulk | |
Part Status | Active | |
Adapter Type | Plug to Jack | |
Adapter Series | SMA to SMA | |
Center Gender | Male to Female | |
Convert From (Adapter End) | SMA Plug, Male Pin | |
Convert To (Adapter End) | SMA Jack, Female Socket | |
Conversion Type | Same Series | |
Impedance | 50 Ohm | |
Style | - | |
Mounting Type | Free Hanging (In-Line), Right Angle | |
Frequency - Max | 18GHz | |
Ingress Protection | - | |
Features | - | |
Body Material | Stainless Steel | |
Body Finish | - | |
Dielectric Material | Polytetrafluoroethylene (PTFE) | |
Center Contact Material | - | |
Center Contact Plating | Gold | |
Mating Cycles | 1000 | |
Standard Package | 10 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HRM-503(40) | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HRM-503(40) is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of HRM-503(40) is new and unused, you can buy HRM-503(40) Hirose Electric Co Ltd with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HRM-503(40).
