Manufacturer Part Number: | HR12-14RA-20SDL |
---|---|
Manufacturer: | Hirose Electric Co Ltd |
Product Category: | Circular Connectors |
Available Quantity: | 9018 Pieces |
Unit Price: | Quote by Email |
Description: | 20 Position Circular Connector Receptacle, Female Sockets Solder Silver |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HR12-14RA-20SDL Datasheet |
Internal Part Number | 898-HR12-14RA-20SDL | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | HR12 Series | |
Category | Connectors, Interconnects | |
Family | Circular Connectors | |
Manufacturer | Hirose Electric Co Ltd | |
Series | HR12 | |
Packaging | Tray | |
Part Status | Active | |
Connector Type | Receptacle, Female Sockets | |
Number of Positions | 20 | |
Shell Size - Insert | 14 | |
Shell Size, MIL | - | |
Mounting Type | Through Hole, Right Angle | |
Termination | Solder | |
Fastening Type | Push-Pull | |
Orientation | Keyed | |
Ingress Protection | - | |
Shell Material, Finish | Brass and Zinc, Nickel Plated | |
Contact Finish | Silver | |
Features | Board Lock, Shielded | |
Contact Finish Thickness | - | |
Current Rating | 2A | |
Voltage - Rated | 100VAC | |
Operating Temperature | -15°C ~ 60°C | |
Standard Package | 10 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HR12-14RA-20SDL | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HR12-14RA-20SDL is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of HR12-14RA-20SDL is new and unused, you can buy HR12-14RA-20SDL Hirose Electric Co Ltd with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HR12-14RA-20SDL.
