| Manufacturer Part Number: | HMC814 |
|---|---|
| Manufacturer: | Analog Devices Inc. |
| Product Category: | RF Misc ICs and Modules |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF IC Frequency Multiplier VSAT 13GHz ~ 24.6GHz Die |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | HMC814 Datasheet |
| Internal Part Number | 898-HMC814 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | IoT Product Selector | |
| Category | RF/IF and RFID | |
| Family | RF Misc ICs and Modules | |
| Manufacturer | Analog Devices Inc. | |
| Series | - | |
| Packaging | Bulk | |
| Part Status | Active | |
| Function | Frequency Multiplier | |
| Frequency | 13GHz ~ 24.6GHz | |
| RF Type | VSAT | |
| Secondary Attributes | - | |
| Package / Case | Die | |
| Supplier Device Package | Die | |
| Standard Package | 50 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | HMC814 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
HMC814 is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of HMC814 is new and unused, you can buy HMC814 Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HMC814.
