Manufacturer Part Number: | HMC344LC3TR |
---|---|
Manufacturer: | Analog Devices Inc. |
Product Category: | RF Switches |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | RF Switch IC Radar SP4T 8GHz 50 Ohm 16-CSMT (3x3) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HMC344LC3TR Datasheet |
Internal Part Number | 898-HMC344LC3TR | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | IoT Product Selector | |
PCN Obsolescence/ EOL | RF/Microwave Dev EOL 3/Mar/2016 | |
Category | RF/IF and RFID | |
Family | RF Switches | |
Manufacturer | Analog Devices Inc. | |
Series | - | |
Packaging | Tape & Reel (TR) | |
Part Status | Last Time Buy | |
Frequency - Lower | 0Hz | |
Frequency - Upper | 8GHz | |
Isolation @ Frequency | 40dB @ 8GHz (typ) | |
Insertion Loss @ Frequency | 2.5dB @ 8GHz | |
IIP3 | 43dBm (typ) | |
Topology | Absorptive | |
Circuit | SP4T | |
P1dB | 26dBm | |
Features | - | |
Impedance | 50 Ohm | |
Operating Temperature | -40°C ~ 85°C | |
Voltage - Supply | - | |
RF Type | Radar | |
Package / Case | 16-VFCQFN Exposed Pad | |
Supplier Device Package | 16-CSMT (3x3) | |
Standard Package | 100 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HMC344LC3TR | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HMC344LC3TR is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of HMC344LC3TR is new and unused, you can buy HMC344LC3TR Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HMC344LC3TR.
