| Manufacturer Part Number: | HMC322-SX |
|---|---|
| Manufacturer: | Analog Devices Inc. |
| Product Category: | RF Switches |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF Switch IC VSAT SP8T 10GHz 50 Ohm Die |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | HMC322-SX Datasheet |
| Internal Part Number | 898-HMC322-SX | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | IoT Product Selector | |
| PCN Obsolescence/ EOL | RF/Microwave Dev EOL 3/Mar/2016 | |
| Category | RF/IF and RFID | |
| Family | RF Switches | |
| Manufacturer | Analog Devices Inc. | |
| Series | - | |
| Packaging | Tray | |
| Part Status | Last Time Buy | |
| Frequency - Lower | 0Hz | |
| Frequency - Upper | 10GHz | |
| Isolation @ Frequency | 32dB @ 6GHz (typ) | |
| Insertion Loss @ Frequency | 2.1dB @ 6GHz | |
| IIP3 | 38dBm (typ) | |
| Topology | Absorptive | |
| Circuit | SP8T | |
| P1dB | 23dBm (typ) IP1dB | |
| Features | - | |
| Impedance | 50 Ohm | |
| Operating Temperature | -40°C ~ 85°C | |
| Voltage - Supply | - | |
| RF Type | VSAT | |
| Package / Case | Die | |
| Supplier Device Package | Die | |
| Standard Package | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | HMC322-SX | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
HMC322-SX is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of HMC322-SX is new and unused, you can buy HMC322-SX Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HMC322-SX.
