Manufacturer Part Number: | HM66-80330LFTR13 |
---|---|
Manufacturer: | TT Electronics/BI Magnetics |
Product Category: | Fixed Inductors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 33µH Shielded Wirewound Inductor 2.3A 93 mOhm Max Nonstandard |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HM66-80330LFTR13 Datasheet |
Internal Part Number | 898-HM66-80330LFTR13 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | Cert. of Compliance | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | TT Electronics/BI Magnetics | |
Series | HM66 | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Wirewound | |
Material - Core | - | |
Inductance | 33µH | |
Tolerance | ±20% | |
Current Rating | 2.3A | |
Current - Saturation | - | |
Shielding | Shielded | |
DC Resistance (DCR) | 93 mOhm Max | |
Q @ Freq | - | |
Frequency - Self Resonant | - | |
Ratings | - | |
Operating Temperature | -40°C ~ 125°C | |
Frequency - Test | 100kHz | |
Mounting Type | Surface Mount | |
Package / Case | Nonstandard | |
Size / Dimension | 0.402" L x 0.394" W (10.20mm x 10.00mm) | |
Height - Seated (Max) | 0.157" (4.00mm) | |
Standard Package | 800 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HM66-80330LFTR13 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HM66-80330LFTR13 is in stock for immediate shipping now. We are the distributor of TT Electronics/BI Magnetics all series components. The condition of HM66-80330LFTR13 is new and unused, you can buy HM66-80330LFTR13 TT Electronics/BI Magnetics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HM66-80330LFTR13.
