| Manufacturer Part Number: | HIP2103FRTAAZ |
|---|---|
| Manufacturer: | Intersil |
| Product Category: | PMIC - Gate Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC DRVR HALF BRIDGE 60V 8-DFN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | HIP2103FRTAAZ Datasheet |
| Internal Part Number | 898-HIP2103FRTAAZ | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Reference Design Library | HIP2103-4DEMO1Z: 3-Ph BLDC, 20A, 13 ~ 50V in | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Manufacturer | Intersil | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Active | |
| Driven Configuration | Half-Bridge | |
| Channel Type | Independent | |
| Number of Drivers | 2 | |
| Gate Type | N-Channel MOSFET | |
| Voltage - Supply | 4.5 V ~ 14 V | |
| Logic Voltage - VIL, VIH | 1.63V, 2.06V | |
| Current - Peak Output (Source, Sink) | 1A, 1A | |
| Input Type | Non-Inverting | |
| High Side Voltage - Max (Bootstrap) | 60V | |
| Rise / Fall Time (Typ) | 8ns, 2ns | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-WDFN Exposed Pad | |
| Supplier Device Package | 8-TDFN (3x3) | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | HIP2103FRTAAZ | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
HIP2103FRTAAZ is in stock for immediate shipping now. We are the distributor of Intersil all series components. The condition of HIP2103FRTAAZ is new and unused, you can buy HIP2103FRTAAZ Intersil with us at a very low price and quick delivery.
