HIF3BAF-16PA-2.54DSA(71)

HIF3BAF-16PA-2.54DSA(71)
Manufacturer Part Number:HIF3BAF-16PA-2.54DSA(71)
Manufacturer:
Product Category:Rectangular Connectors - Headers, Male Pins
Available Quantity:9165 Pieces
Unit Price:Quote by Email
Description:16 Positions Header, Shrouded Connector 0.100" (2.54mm) Through Hole Gold
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: HIF3BAF-16PA-2.54DSA(71) Datasheet
HIF3BAF-16PA-2.54DSA(71)´s Parameters
Internal Part Number898-HIF3BAF-16PA-2.54DSA(71)
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog HIF3B Series
CategoryConnectors, Interconnects
FamilyRectangular Connectors - Headers, Male Pins
ManufacturerHirose Electric Co Ltd
SeriesHIF3B
PackagingBulk
Part StatusActive
Contact TypeMale Pin
Connector TypeHeader, Shrouded
Number of Positions16
Number of Positions LoadedAll
Pitch0.100" (2.54mm)
Number of Rows2
Row Spacing0.100" (2.54mm)
Contact Mating Length0.236" (6.00mm)
Mounting TypeThrough Hole
TerminationSolder
Fastening TypeLatch Lock/Eject Hooks
Features-
Contact FinishGold
Contact Finish Thickness8µin (0.20µm)
ColorBlack
Standard Package 160
Weight0.001 KG
ApplicationEmail for details
Replacement PartHIF3BAF-16PA-2.54DSA(71)
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

HIF3BAF-16PA-2.54DSA(71) is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of HIF3BAF-16PA-2.54DSA(71) is new and unused, you can buy HIF3BAF-16PA-2.54DSA(71) Hirose Electric Co Ltd with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for HIF3BAF-16PA-2.54DSA(71).
