Manufacturer Part Number: | HF12-1A54-8 |
---|---|
Manufacturer: | Standex-Meder Electronics |
Product Category: | Signal Relays, Up to 2 Amps |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | RF Relay SPST-NO (1 Form A) Through Hole |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HF12-1A54-8 Datasheet |
Internal Part Number | 898-HF12-1A54-8 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Magnetic Mapping | |
Category | Relays | |
Family | Signal Relays, Up to 2 Amps | |
Manufacturer | Standex-Meder Electronics | |
Series | HF | |
Packaging | Bulk | |
Part Status | Active | |
Relay Type | RF | |
Coil Type | Non Latching | |
Coil Current | 47.9mA | |
Coil Voltage | 12VDC | |
Contact Form | SPST-NO (1 Form A) | |
Contact Rating (Current) | 1.5A | |
Switching Voltage | 500VAC, 500VDC - Max | |
Turn On Voltage (Max) | 8.4 VDC | |
Turn Off Voltage (Min) | 1.8 VDC | |
Operate Time | 3ms | |
Release Time | 1ms | |
Features | - | |
Mounting Type | Through Hole | |
Termination Style | PC Pin | |
Contact Material | - | |
Coil Power | 575 mW | |
Coil Resistance | 250 Ohms | |
Operating Temperature | -40°C ~ 85°C | |
Standard Package | 12 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HF12-1A54-8 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HF12-1A54-8 is in stock for immediate shipping now. We are the distributor of Standex-Meder Electronics all series components. The condition of HF12-1A54-8 is new and unused, you can buy HF12-1A54-8 Standex-Meder Electronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HF12-1A54-8.
