Manufacturer Part Number: | HDSP-H2G1 |
---|---|
Manufacturer: | Broadcom Limited |
Product Category: | Display Modules - LED Character and Numeric |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Character LED Display Module Green 7-Segment 1 Character Common Anode 4V 20mA 2.744" H x 1.882" W x 0.472" D (69.70mm x 47.80mm x 12.00mm) 10-DIP (2.370", 60.20mm) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | HDSP-H2G1 Datasheet |
Internal Part Number | 898-HDSP-H2G1 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Category | Optoelectronics | |
Family | Display Modules - LED Character and Numeric | |
Manufacturer | Broadcom Limited | |
Series | - | |
Packaging | Tube | |
Part Status | Active | |
Number of Characters | 1 | |
Size / Dimension | 2.744" H x 1.882" W x 0.472" D (69.70mm x 47.80mm x 12.00mm) | |
Digit/Alpha Size | 2.30" (58.42mm) | |
Display Type | 7-Segment | |
Common Pin | Common Anode | |
Color | Green | |
Voltage - Forward (Vf) (Typ) | 4V | |
Current - Test | 20mA | |
Millicandela Rating | 38mcd | |
Wavelength - Peak | 570nm | |
Power Dissipation (Max) | 208mW | |
Package / Case | 10-DIP (2.370", 60.20mm) | |
Standard Package | 60 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | HDSP-H2G1 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
HDSP-H2G1 is in stock for immediate shipping now. We are the distributor of Broadcom Limited all series components. The condition of HDSP-H2G1 is new and unused, you can buy HDSP-H2G1 Broadcom Limited with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for HDSP-H2G1.
