Manufacturer Part Number: | H2157-01 |
---|---|
Manufacturer: | Harwin Inc. |
Product Category: | Terminals - PC Pin, Single Post Connectors |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | PC Pin Terminal Connector Through Hole Tin 0.050" (1.27mm) Dia |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | H2157-01 Datasheet |
Internal Part Number | 898-H2157-01 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Spacers, Terminals, and PCB Sockets | |
PCN Obsolescence/ EOL | H2156-01,H2157-01,H3150-01,H3151-01 03/Jun/2015 | |
Category | Connectors, Interconnects | |
Family | Terminals - PC Pin, Single Post Connectors | |
Manufacturer | Harwin Inc. | |
Series | - | |
Packaging | Bulk | |
Part Status | Obsolete | |
Terminal Type | PC Pin | |
Terminal Style | Single End | |
Pin Size - Above Flange | 0.050" (1.27mm) Dia | |
Pin Size - Below Flange | 0.050" (1.27mm) Dia | |
Length Above Flange | 0.449" (11.40mm) | |
Length Below Flange | 0.030" (0.76mm) | |
Length - Overall | 0.504" (12.80mm) | |
Flange Diameter | 0.088" (2.24mm) | |
Mounting Hole Diameter | 0.055" ~ 0.059" (1.40mm ~ 1.50mm) | |
Mounting Type | Through Hole | |
Termination | Swage | |
Insulation | Non-Insulated | |
Board Thickness | 0.063" ~ 0.094" (1.60mm ~ 2.39mm) | |
Contact Material | Brass | |
Contact Finish | Tin | |
Contact Finish Thickness | 300µin (7.62µm) | |
Material - Insulation | - | |
Insulation Color | - | |
Standard Package | 1,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | H2157-01 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
H2157-01 is in stock for immediate shipping now. We are the distributor of Harwin Inc. all series components. The condition of H2157-01 is new and unused, you can buy H2157-01 Harwin Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for H2157-01.
