| Manufacturer Part Number: | GPIODM-KPLCD |
|---|---|
| Manufacturer: | Microchip Technology |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9011 Pieces |
| Unit Price: | Quote by Email |
| Description: | MCP23008, MCP23S08, MCP23017, MCP23S17, PIC18F4550, MCP1702 - Interface, Front Panel Controller, LCD Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | GPIODM-KPLCD Datasheet |
| Internal Part Number | 898-GPIODM-KPLCD | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Reference Design Library | GPIODM-KPLCD: 8/16-Bit GPIO Exp, 4x4 Keypad, LCD | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Online Catalog | MCP23X08/17 GPIO Exp Keypad/LCD Demo Board | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | Microchip Technology | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | Interface, Front Panel Controller, LCD | |
| Embedded | Yes, MCU, 8-Bit | |
| Utilized IC / Part | MCP23008, MCP23S08, MCP23017, MCP23S17, PIC18F4550, MCP1702 | |
| Primary Attributes | (2) 8-Bit and (2) 16-Bit GPIO Expanders, 4x4 Keypad, 2x16 LCD | |
| Secondary Attributes | Headers for the MCP23x08 and MCP23x17 | |
| Supplied Contents | Board | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | GPIODM-KPLCD | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
GPIODM-KPLCD is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of GPIODM-KPLCD is new and unused, you can buy GPIODM-KPLCD Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for GPIODM-KPLCD.
