| Manufacturer Part Number: | GLK12232-25-SM-R14 |
|---|---|
| Manufacturer: | Matrix Orbital |
| Product Category: | Display Modules - LCD, OLED, Graphic |
| Available Quantity: | 9017 Pieces |
| Unit Price: | Quote by Email |
| Description: | Graphic LCD Display Module Transmissive White (Gray - Inverted) Monochrome I²C, RS232, TTL 122 x 32 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | GLK12232-25-SM-R14 Datasheet |
| Internal Part Number | 898-GLK12232-25-SM-R14 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | GLK12232-25 Backlight LED's 05/Jan/2010 | |
| Category | Optoelectronics | |
| Family | Display Modules - LCD, OLED, Graphic | |
| Manufacturer | Matrix Orbital | |
| Series | - | |
| Part Status | Obsolete | |
| Display Type | Monochrome | |
| Display Mode | Transmissive | |
| Touchscreen | - | |
| Diagonal Screen Size | - | |
| Viewing Area | 53.64mm W x 14.04mm H | |
| Backlight | LED - White | |
| Dot Pixels | 122 x 32 | |
| Interface | I²C, RS232, TTL | |
| Graphics Color | White (Gray - Inverted) | |
| Background Color | Gray (White - Inverted) | |
| Dot Size | 0.40mm W x 0.40mm H | |
| Dot Pitch | 0.44mm W x 0.44mm H | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | GLK12232-25-SM-R14 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
GLK12232-25-SM-R14 is in stock for immediate shipping now. We are the distributor of Matrix Orbital all series components. The condition of GLK12232-25-SM-R14 is new and unused, you can buy GLK12232-25-SM-R14 Matrix Orbital with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for GLK12232-25-SM-R14.
