Manufacturer Part Number: | G2-DB02-ST |
---|---|
Manufacturer: | Crydom Co. |
Product Category: | Solid State Relays |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Solid State Relay DPST (2 Form B) 8-SMD (0.300", 7.62mm) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | |
Production Status (Lifecycle): | Obsolete / Discontinued |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | G2-DB02-ST Datasheet |
Internal Part Number | 898-G2-DB02-ST | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Other Related Documents | Declaration of Conformity | |
Category | Relays | |
Family | Solid State Relays | |
Manufacturer | Crydom Co. | |
Series | G2 | |
Packaging | Cut Tape (CT) | |
Part Status | Obsolete | |
Circuit | DPST (2 Form B) | |
Output Type | AC, DC | |
On-State Resistance (Max) | 13 Ohm | |
Load Current | 200mA | |
Voltage - Input | 1.2VDC | |
Voltage - Load | 0 ~ 250 V | |
Mounting Type | Surface Mount | |
Termination Style | Gull Wing | |
Package / Case | 8-SMD (0.300", 7.62mm) | |
Supplier Device Package | 8-SMD | |
Relay Type | Relay | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | G2-DB02-ST | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
G2-DB02-ST is in stock for immediate shipping now. We are the distributor of Crydom Co. all series components. The condition of G2-DB02-ST is new and unused, you can buy G2-DB02-ST Crydom Co. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for G2-DB02-ST.
