| Manufacturer Part Number: | FX30B-3P-3.81DSA25 |
|---|---|
| Manufacturer: | Hirose Electric Co Ltd |
| Product Category: | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Available Quantity: | 9062 Pieces |
| Unit Price: | Quote by Email |
| Description: | CONN HEADER 3POS PCB VERT |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | FX30B-3P-3.81DSA25 Datasheet |
| Internal Part Number | 898-FX30B-3P-3.81DSA25 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | Hirose FunctionMAX Board-to-Board Connectors | Digi-Key Daily | |
| Featured Product | FX30B Series Power Connector Systems | |
| Online Catalog | FunctionMax™ FX30B Series | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins | |
| Manufacturer | Hirose Electric Co Ltd | |
| Series | FunctionMax™ FX30B | |
| Packaging | Tray | |
| Part Status | Active | |
| Connector Type | Shrouded | |
| Number of Positions | 3 | |
| Number of Positions Loaded | All | |
| Pitch | 0.150" (3.81mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Height Stacking (Mating) | 0.984" (25.00mm) | |
| Molding Height Above Board | 0.756" (19.20mm) | |
| Contact Mating Length | - | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 3.9µin (0.10µm) | |
| Features | Board Guide, Board Lock | |
| Color | Black | |
| Standard Package | 42 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | FX30B-3P-3.81DSA25 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
FX30B-3P-3.81DSA25 is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of FX30B-3P-3.81DSA25 is new and unused, you can buy FX30B-3P-3.81DSA25 Hirose Electric Co Ltd with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for FX30B-3P-3.81DSA25.
