| Manufacturer Part Number: | FSA2859UCX |
|---|---|
| Manufacturer: | Fairchild Semiconductor |
| Product Category: | Interface - Analog Switches, Multiplexers, Demultiplexers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 2 Circuit IC Switch 2:2 750 mOhm 12-WLCSP (1.9x1.4) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | FSA2859UCX Datasheet |
| Internal Part Number | 898-FSA2859UCX | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Analog Switches, Multiplexers, Demultiplexers | |
| Manufacturer | Fairchild Semiconductor | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Switch Circuit | DPDT | |
| Multiplexer/Demultiplexer Circuit | 2:2 | |
| Number of Circuits | 2 | |
| On-State Resistance (Max) | 750 mOhm | |
| Channel-to-Channel Matching (ΔRon) | 50 mOhm | |
| Voltage - Supply, Single (V+) | 1.65 V ~ 5.5 V | |
| Voltage - Supply, Dual (V±) | - | |
| Switch Time (Ton, Toff) (Max) | 25ns, 20ns | |
| -3db Bandwidth | 60MHz | |
| Charge Injection | 47pC | |
| Channel Capacitance (CS(off), CD(off)) | 50pF | |
| Current - Leakage (IS(off)) (Max) | 10nA | |
| Crosstalk | -65dB @ 1MHz | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 12-UFBGA, WLCSP | |
| Supplier Device Package | 12-WLCSP (1.9x1.4) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | FSA2859UCX | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
FSA2859UCX is in stock for immediate shipping now. We are the distributor of Fairchild Semiconductor all series components. The condition of FSA2859UCX is new and unused, you can buy FSA2859UCX Fairchild Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for FSA2859UCX.
