| Manufacturer Part Number: | FRDM-STBC-SA9500 |
|---|---|
| Manufacturer: | NXP Semiconductors |
| Product Category: | Evaluation Boards - Sensors |
| Available Quantity: | 9016 Pieces |
| Unit Price: | Quote by Email |
| Description: | FXLC95000CL - Accelerometer, 3 Axis Sensor Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | FRDM-STBC-SA9500 Datasheet |
| Internal Part Number | 898-FRDM-STBC-SA9500 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | BRKT-STBC-SA9500 BOM, Design Files FRDM-K22F-SA9500 Schematic | |
| Online Catalog | FXLC95000CL Intelligent Motion Sensor Breakout Boards | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - Sensors | |
| Manufacturer | Freescale Semiconductor - NXP | |
| Series | - | |
| Part Status | Active | |
| Sensor Type | Accelerometer, 3 Axis | |
| Sensing Range | ±2g, 4g, 8g | |
| Interface | I²C, SPI | |
| Sensitivity | 0.061mg/LSB, 0.122mg/LSB, 0.244mg/LSB | |
| Voltage - Supply | 1.71 V ~ 1.89 V | |
| Embedded | Yes, MCU, 32-Bit | |
| Supplied Contents | Board | |
| Utilized IC / Part | FXLC95000CL | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | FRDM-STBC-SA9500 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
FRDM-STBC-SA9500 is in stock for immediate shipping now. We are the distributor of NXP Semiconductors all series components. The condition of FRDM-STBC-SA9500 is new and unused, you can buy FRDM-STBC-SA9500 NXP Semiconductors with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for FRDM-STBC-SA9500.
