FH35-45S-0.3SHW(50)

FH35-45S-0.3SHW(50)
Manufacturer Part Number:FH35-45S-0.3SHW(50)
Manufacturer:
Product Category:FFC, FPC (Flat Flexible) Connectors
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:45 Position FPC Connector Contacts, Top 0.012" (0.30mm) Surface Mount, Right Angle
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):Obsolete / Discontinued
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: FH35-45S-0.3SHW(50) Datasheet
FH35-45S-0.3SHW(50)´s Parameters
Internal Part Number898-FH35-45S-0.3SHW(50)
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
CategoryConnectors, Interconnects
FamilyFFC, FPC (Flat Flexible) Connectors
ManufacturerHirose Electric Co Ltd
SeriesFH35
PackagingTape & Reel (TR)
Part StatusObsolete
Flat Flex TypeFPC
Mounting TypeSurface Mount, Right Angle
Connector/Contact TypeContacts, Top
Number of Positions45
Pitch0.012" (0.30mm)
TerminationSolder
FFC, FCB Thickness0.20mm
Height Above Board0.036" (0.90mm)
Locking FeatureRotary Lock, Backlock
Cable End TypeTapered
Contact MaterialPhosphor Bronze
Contact FinishGold
Housing MaterialLiquid Crystal Polymer (LCP)
Actuator MaterialPolyamide (PA), Nylon
FeaturesZero Insertion Force (ZIF)
Voltage Rating30V
Operating Temperature-55°C ~ 85°C
Material Flammability RatingUL94 V-0
Current Rating0.2A
Standard Package 5,000
Weight0.001 KG
ApplicationEmail for details
Replacement PartFH35-45S-0.3SHW(50)
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

FH35-45S-0.3SHW(50) is in stock for immediate shipping now. We are the distributor of Hirose Electric Co Ltd all series components. The condition of FH35-45S-0.3SHW(50) is new and unused, you can buy FH35-45S-0.3SHW(50) Hirose Electric Co Ltd with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for FH35-45S-0.3SHW(50).
