| Manufacturer Part Number: | FEBFAN7688SJXA_CP14U306 |
|---|---|
| Manufacturer: | Fairchild Semiconductor |
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Available Quantity: | 9012 Pieces |
| Unit Price: | Quote by Email |
| Description: | FAN7688 - AC/DC, Secondary Side 2, Isolated Outputs Evaluation Board |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | FEBFAN7688SJXA_CP14U306 Datasheet |
| Internal Part Number | 898-FEBFAN7688SJXA_CP14U306 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | FAN7688 Resonant Converter Controller | |
| Online Catalog | FAN7688 Evaluation Boards | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Manufacturer | Fairchild Semiconductor | |
| Series | - | |
| Part Status | Active | |
| Main Purpose | AC/DC, Secondary Side | |
| Outputs and Type | 2, Isolated | |
| Power - Output | 306W | |
| Voltage - Output | 12V, 12V | |
| Current - Output | - | |
| Voltage - Input | 90 ~ 264 VAC | |
| Regulator Topology | - | |
| Frequency - Switching | - | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | FAN7688 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | FEBFAN7688SJXA_CP14U306 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
