Manufacturer Part Number: | EVB-LAN9252-HBI |
---|---|
Manufacturer: | Microchip Technology |
Product Category: | Evaluation and Demonstration Boards and Kits |
Available Quantity: | 9027 Pieces |
Unit Price: | Quote by Email |
Description: | LAN9252 - Interface, Ethernet Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | EVB-LAN9252-HBI Datasheet |
Internal Part Number | 898-EVB-LAN9252-HBI | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | LAN9252-HBI & SPI+GPIO BOM EVB-LAN9252-HBI-Eval Brd Gerber files LAN9252-HBI & SPI+GPIO-EVB Schematics Development Tool Selector | |
PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
Online Catalog | LAN9252 EtherCAT® Slave Controller with HBI PDI Interface Evaluation Board | |
Category | Programmers, Development Systems | |
Family | Evaluation and Demonstration Boards and Kits | |
Manufacturer | Microchip Technology | |
Series | - | |
Part Status | Active | |
Main Purpose | Interface, Ethernet | |
Embedded | - | |
Utilized IC / Part | LAN9252 | |
Primary Attributes | EtherCAT Slave Controller | |
Secondary Attributes | LED Status Indicators | |
Supplied Contents | Board | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | EVB-LAN9252-HBI | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
EVB-LAN9252-HBI is in stock for immediate shipping now. We are the distributor of Microchip Technology all series components. The condition of EVB-LAN9252-HBI is new and unused, you can buy EVB-LAN9252-HBI Microchip Technology with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for EVB-LAN9252-HBI.
