Manufacturer Part Number: | EVAL01-HMC1060LP3E |
---|---|
Manufacturer: | Analog Devices Inc. |
Product Category: | Evaluation Boards - Linear Voltage Regulators |
Available Quantity: | 9014 Pieces |
Unit Price: | Quote by Email |
Description: | HMC1060LP3E 4 - Quad Channels per IC Positive Adjustable Linear Voltage Regulator Evaluation Board |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | EVAL01-HMC1060LP3E Datasheet |
Internal Part Number | 898-EVAL01-HMC1060LP3E | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Development Tool Selector | |
Online Catalog | HMC1060 Evaluation Board | |
Category | Programmers, Development Systems | |
Family | Evaluation Boards - Linear Voltage Regulators | |
Manufacturer | Analog Devices Inc. | |
Series | - | |
Part Status | Active | |
Channels per IC | 4 - Quad | |
Voltage - Output | 1.8 V ~ 5.2 V | |
Current - Output | 300mA, 100mA, 50mA, 50mA | |
Voltage - Input | 3.35 V ~ 5.6 V | |
Regulator Type | Positive Adjustable | |
Operating Temperature | -40°C ~ 85°C | |
Board Type | Fully Populated | |
Supplied Contents | Board | |
Utilized IC / Part | HMC1060LP3E | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | EVAL01-HMC1060LP3E | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
EVAL01-HMC1060LP3E is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of EVAL01-HMC1060LP3E is new and unused, you can buy EVAL01-HMC1060LP3E Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for EVAL01-HMC1060LP3E.
