Manufacturer Part Number: | ES125D10-Z |
---|---|
Manufacturer: | Copal Electronics Inc. |
Product Category: | Slide Switches |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | Slide Switch SPDT Panel Mount |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ES125D10-Z Datasheet |
Internal Part Number | 898-ES125D10-Z | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Slide Switch | |
Category | Switches | |
Family | Slide Switches | |
Manufacturer | Copal Electronics Inc. | |
Series | ES | |
Packaging | Bulk | |
Part Status | Active | |
Circuit | SPDT | |
Contact Timing | Non-Shorting (BBM) | |
Switch Function | On-On | |
Current Rating | 25A (AC) | |
Voltage Rating - AC | 125V | |
Voltage Rating - DC | - | |
Actuator Type | Standard | |
Actuator Length | 9.00mm | |
Contact Material | - | |
Contact Finish | - | |
Mounting Type | Panel Mount | |
Termination Style | Screw Terminal | |
Features | - | |
Actuator Material | - | |
Switch Travel | 8.00mm | |
Operating Temperature | - | |
Mechanical Life | - | |
Electrical Life | 20,000 Cycles | |
Operating Force | - | |
Standard Package | 10 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ES125D10-Z | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ES125D10-Z is in stock for immediate shipping now. We are the distributor of Copal Electronics Inc. all series components. The condition of ES125D10-Z is new and unused, you can buy ES125D10-Z Copal Electronics Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ES125D10-Z.
