| Manufacturer Part Number: | EPC9001 |
|---|---|
| Manufacturer: | EPC |
| Product Category: | Evaluation and Demonstration Boards and Kits |
| Available Quantity: | 9049 Pieces |
| Unit Price: | Quote by Email |
| Description: | EPC2015 eGaN® Series Power Management, Half H-Bridge Driver (External FET) Evaluation Board |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | EPC9001 Datasheet |
| Internal Part Number | 898-EPC9001 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Thermal Performance of eGaN® FETs Assembling eGaN® FETs Using eGaN® FETs | |
| Product Training Modules | eGaN™ Basics eGan® FET's Characteristics Driving eGaN® Power Transistors eGaN FETs for DC-DC Conversion Driving eGaN FETs with LM5113 | |
| Video File | EPC eGaN FETs -- Another Geek Moment | DigiKey | |
| RoHS Information | Lead Free/RoHS Statement | |
| Design Resources | EPC9001 Schematic EPC9001 Gerber Files EPC9001 Bill of Materials Development Tool Selector | |
| Featured Product | EPC Development Tools EPC Low Voltage eGaN® FETs | |
| Online Catalog | EPC2015 Development Boards | |
| Category | Programmers, Development Systems | |
| Family | Evaluation and Demonstration Boards and Kits | |
| Manufacturer | EPC | |
| Series | eGaN® | |
| Part Status | Active | |
| Main Purpose | Power Management, Half H-Bridge Driver (External FET) | |
| Embedded | No | |
| Utilized IC / Part | EPC2015 | |
| Primary Attributes | 40V, 15A Max Output GaNFET Capability | |
| Secondary Attributes | GaNFET Driver Circuit Uses 7V ~ 12V | |
| Supplied Contents | Board | |
| Standard Package | 40 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | EPC9001 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
EPC9001 is in stock for immediate shipping now. We are the distributor of EPC all series components. The condition of EPC9001 is new and unused, you can buy EPC9001 EPC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for EPC9001.
